| Description | SPECIFICATIONS
- DC Voltage :
Range : 200mV / 2V / 20V / 200V/ 600V
Resolution : 0.1mV/1mV/10mV/0.1V/1V
Accuracy :±(0.5%+3) ; ±(0.8%+5)
- AC Voltage :
Range : 200V / 600V
Resolution : 0.1V/1V
Accuracy : ±(1.2%+5)
- DC Current :
Range : 20μA/200μA/2mA/20mA/200mA / 10A
Resolution : 0.01μA/0.1μA/1μA/10μA/0.1mA /10mA
Accuracy : ±(1.0%+3) / ±(3%+10)
- Resistance :
Range : 200Ω To 2MΩ
Resolution : 0.1Ω To 1kΩ
Accuracy : ±(0.8%+5) To ±(1.0%+5)
- Power Supply : 1x9V 6F22 Battery
- Product Size : 145mmx76mmx40mm/5.7"x3"x1.57"
- Product Weight : 202g/0.44lb
- Certificate : CE / ETL / RoHS
FEATURES
- Display 2000 counts
- Diode Open Voltage 3.0V
- Data Hold
- Low Battery Display
- Continuity Buzzer <70 ±30Ω
- Display Backlight
| SPECIFICATIONS
- DC Voltage : 1000V
- AC Voltage : 750V
- DCA : 20A
- ACA : 20A
- Capacitance : 200uF
- Resistance : 2000MΩ
- Frequency: 200kHz
- Temperature : -20°C to 1000°C
FEATURES
- Display Mode: 31/2 LCD display
- Maximum Display: 1999, updates every 2-3s
- Measuring method: Dual – slope integration A/D converter
- AC & DC Voltage
- AC & DC Current
- Capacitance
- Resistance
- Frequency
- Temperature
- Over range display: “1” displayed
- Low battery indication:
- Polarity indication: “-” displayed for negative polarity
- Display Mode: 31/2 LCD display
- Maximum Display: 1999, updates every 2-3s
- Measuring method: Dual – slope integration A/D converter
- AC & DC Voltage
- AC & DC Current
- Capacitance
- Resistance
- Frequency
- Temperature
- Over range display: “1” displayed
- Low battery indication:
- Polarity indication: “-” displayed for negative polarity
- Power supply: 9V
- Dimensions: 189(L) x 91(W) x 31.5mm(H)
- Weight: ≈ 280g (battery included)
- Operating environment: 0˚C ~ 40˚C
- Storage environment: -10˚C ~ 50˚C
- Accuracies are guaranteed for 1 year, 18˚C - 28 ˚C , less than 80% RH
- Fuse protection: F 500mA/250V
- Maximum voltage between terminals and earth ground: 1000VDC or 700VAC
| SPECIFICATIONS :
- AC VOLTAGE : Up to 750 V
- DC VOLTAGE : Up to 1000 V
- AC RESPONSE : 40 Hz ~ 1 KHz
- ACCURACY : +-(0.8% rdg + 5 dgt)
- DC CURRENT : 10 A
- RESISTANCE : Up to 60 MOhm
- CAPACITANCE : Up to 100 mF
- DIMENSIONS : 147 x 71 x 45 mm
FEATURES :
- 3 5/6 Digits
- 6000 Counts
- TRMS
- Auto Ranging
- NCV (LED, Buzzer & EF Strength)
- Continuity Test (LED, Buzzer & EF Strength)
- LCD with Backlight
- Data Hold
- Auto Power Off
- Holster with Magnet
- Torch Light
- Test Lead Gripper
- Low Battery Indication
| SPECIFICATION:
- DC Voltage: 200mV/2V/20V/200V/1000V, ±(0.5% + 4)
- AC Voltage: 200mV/2V/20V/200V/750V,±(0.8% + 5)
- DC Current: 200uA/2mA/20mA/20mA/2A/20A, ±(1.0% + 5)
- AC Current: 200uA/2mA/20mA/20mA/2A/20A, ±(1.5% + 5)
- Resistance: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ, ±(0.8% + 1)
- Temperature: -40 ~ 1000 °C / 0 ~ 1832 °F ±(1.0% + 5)
- Dimensions : 170(H) x 86(W) x 35(D)mm
FEATURES:
- 3 ½ Digital Multimeter, 1999 Counts
- Auto Power Off (APO) under natural operation
- Non Contact Voltage (NCV) Test
- Backlight LCD
SPECIAL FUNCTION:
- Diode Test NCV
- Transistor Testing Input impedance 10MΩ
- Continuity Buzzer Approx. <30+10 Sampling Rate 3 times per second
- Low Battery Display Approx. <7.5V AC Frequency Response 40-400Hz
- Auto Power OFF Approx. 30 min Power 9V (6F22) x 1
| SPECIFICATIONS :
- DC VOLTAGE : 999.9V
- AC VOLTAGE : 750.0V
- DC CURRENT : 9.999A
- AC CURRENT : 9.999A
- RESISTANCE : 9.999MΩ
- CAPACITANCE : 9.999mF
- FREQUENCY : 9.999MHz
- DUTY CYCLE : 1% ~ 99%
FEATURES :
- LCD with Backlight
- Auto Power Off
- Low Battery Indication
| SPECIFICATIONS
- DC VOLTAGE RANGE : 1000V
- AC VOLTAGE RANGE : 750V
- RESISTANCE RANGE : 200MΩ
- DC CURRENT RANGE : 10A
- AC CURRENT RANGE : 10A
- TRANSISTOR hFE TEST : NPN or PNP
FEATURES
- 3½ Digit Manual Multimeter with Backlight
- Large LCD display with manual range
- Auto Power Off (APO) under natural operation
- Full protection in all Ranges.
|
| Content | With maximum display value of 1999 and polarity display for negative polarity, this digital Multimeter is widely-acknowledged in the market for many academic, industrial, and commercial applications like physics, electronics, electrical, and many more. This device is very useful and effective which makes the work of electricians much simpler and easy. The operating temperature of this Multimeter is 0~40 degree Celsius (32~104 degree Fahrenheit) and the storage temperature is 10~50 degree Celsius (14~122 degree Fahrenheit) | The meter is a hand held 3 ½ digital multimeter for measuring DC and AC voltage, DC and AC current, resistance, diode, transistor, frequency, temperature, capacitance and continuity test with battery operated. The back light of display is optional. This multimeter is designed according to IEC – 1010 concerning electronic measuring instruments with an overvoltage category (CATII) and pollution 2. | | HTC DM-86 Digital Multimeter is a reliable and accurate device that is perfect for a wide range of applications. It features a large, easy-to-read LCD display and a wide variety of functions including AC/DC voltage and current, resistance, capacitance, frequency, and temperature. The HTC 3 digit Digital Multimeter is a professional-grade tool designed for precision measurement of DC and AC voltages, DC current, and resistance. With a large and easy-to-read LCD display, the multimeter is simple to use and provides accurate readings. The DC voltage accuracy is(0.5% + 4 Digit) and the AC voltage accuracy is(0.8% + 5). The DC current accuracy is (1.0% + 5) and the AC current accuracy is(1.5% + 5). The resistance accuracy is (0.8%rdg + 1 dgt). The battery test is 9V/1.5V/3V. The multimeter is compact and lightweight, making it easy to carry and store. | | A multimeter is a device that measures electric variables such as voltage current and resistance A typical multimeter is capable of combining all such measuring functions in single equipment It is also known as a VOM (Volt Ohm millimeter) Previously, analog meters were used by the electrical experts but now digital multimeters have replaced them as they are able to give more accurate results The HTC 0-750 basic digital multimeter offers reliable measurements to the modern electricians working in both residential and commercial segments Also, it helps technicians working on field with heating and air conditioning equipment as well |
